| ICAO Code | Classification | Category |
|---|---|---|
TBM |
L1P |
M/G |
Technical Data
Wing Span (m)
16.5
Length (m)
12.1
Height (m)
4.7
MTOW (t)
7
Fuel Capacity (ltr)
Maximum Range (Nm)
900
Persons On Board
3
Take Off Distance (m)
Landing Distance (m)
Absolute Ceiling (x100ft)
230
Optimum Ceiling (x100ft)
Maximum Speed (kts/M)
278
Optimum Speed (kts/M)
171
Maximum Climb Rate (ft/min)
1075
Manufacturers
GENERAL MOTORS TBM Avenger
GRUMMAN G-40 Avenger
GRUMMAN TBF Avenger
