| ICAO Code | Classification | Category |
|---|---|---|
SH36 |
L2T |
M/G |
Technical Data
Wing Span (m)
22.8
Length (m)
21.6
Height (m)
7.2
MTOW (t)
12.2
Fuel Capacity (ltr)
1740
Maximum Range (Nm)
630
Persons On Board
36-39
Take Off Distance (m)
1320
Landing Distance (m)
1198
Absolute Ceiling (x100ft)
230
Optimum Ceiling (x100ft)
200
Maximum Speed (kts/M)
230
Optimum Speed (kts/M)
210
Maximum Climb Rate (ft/min)
1200
Manufacturers
SHORT 360
SHORT SD3-60
