| ICAO Code | Classification | Category |
|---|---|---|
PA31 |
L2P |
L/G |
Technical Data
Wing Span (m)
12.4
Length (m)
10.5
Height (m)
3.9
MTOW (t)
3.1
Fuel Capacity (ltr)
700
Maximum Range (Nm)
880
Persons On Board
8
Take Off Distance (m)
700
Landing Distance (m)
600
Absolute Ceiling (x100ft)
240
Optimum Ceiling (x100ft)
200
Maximum Speed (kts/M)
212
Optimum Speed (kts/M)
183
Maximum Climb Rate (ft/min)
1300
Manufacturers
AICSA PA-31-310 Navajo
AICSA PA-31-325 Navajo CR
AICSA PA-31-350 Chieftain
AICSA PA-31-350 Navajo Chieftain
CHINCUL PA-A-31-310 Navajo
CHINCUL PA-A-31-325 Navajo CR
CHINCUL PA-A-31-350 Chieftain
CHINCUL PA-A-31-350 Navajo Chieftain
CHINCUL PA-A-31P-425 Pressurized Navajo
COLEMILL Panther 2
COLEMILL Panther 3
COLEMILL Panther Navajo
EMBRAER EMB-820 Navajo
NEIVA EMB-820 Navajo
PIPER PA-31-300 Navajo
PIPER PA-31-310 Navajo
PIPER PA-31-325 Navajo CR
PIPER PA-31-350 Chieftain
PIPER PA-31-350 Navajo Chieftain
PIPER PA-31-350 T-1020
PIPER PA-31P-350 Mojave
PIPER PA-31P-425 Pressurized Navajo
