| ICAO Code | Classification | Category |
|---|---|---|
PA23 |
L2P |
L/G |
Technical Data
Wing Span (m)
11.3
Length (m)
9.5
Height (m)
3
MTOW (t)
2.1
Fuel Capacity (ltr)
135
Maximum Range (Nm)
1030
Persons On Board
1+5
Take Off Distance (m)
520
Landing Distance (m)
400
Absolute Ceiling (x100ft)
240
Optimum Ceiling (x100ft)
180
Maximum Speed (kts/M)
176
Optimum Speed (kts/M)
166
Maximum Climb Rate (ft/min)
1400
Manufacturers
MILLER (1) Jet Profile
PIPER PA-23-150 Apache
PIPER PA-23-160 Apache
SEGUIN Geronimo
