| ICAO Code | Classification | Category |
|---|---|---|
PA18 |
L1P |
L/G |
Technical Data
Wing Span (m)
10.7
Length (m)
6.8
Height (m)
2
MTOW (t)
0.8
Fuel Capacity (ltr)
136
Maximum Range (Nm)
380
Persons On Board
2
Take Off Distance (m)
160
Landing Distance (m)
270
Absolute Ceiling (x100ft)
190
Optimum Ceiling (x100ft)
140
Maximum Speed (kts/M)
113
Optimum Speed (kts/M)
100
Maximum Climb Rate (ft/min)
960
Manufacturers
AIRFRAMES-DAKOTA CUB S-18 Super 18
AMERICAN LEGEND AL-18 Super Legend
AMERICAN LEGEND AL-18 MOAC
BACKCOUNTRY PA-18 Super Cub
CUB CRAFTERS CC-18 Top Cub
CUB CRAFTERS PA-18 Top Cub
PIPER L-18C Super Cub
PIPER L-21 Super Cub
PIPER PA-18 Super Cub
PIPER U-7 Super Cub
SAFAT 01
SMITH AVIATION PA-18 Super Cub
SUPER 18 S-18 Super 18
TURBINE CUBS PA-18 Super Cub
WAGAERO Super Cuby
WAGAERO Super Sport
YAKIMA AEROSPORT Super 18 Turbo Cub
