ICAO CodeClassificationCategory

MOCU

L1P

L

MOCUthumb image
MOCUthumb image
MOCUthumb image

Manufacturers

CULP
MonoCulp

Technical Data

Wing Span
9.7
Length (m)
7.4
Height (m)
2.5
Take Off Distance (m)
130
Landing Distance (m)
300
Absolute Ceiling (x100ft)
120
Optimum Ceiling (x100ft)
80
Maximum Speed (kts/M)
234
Optimum Speed (kts/M)
147
Fuel Capacity (ltr)
320
MTOW (t)
1.3
Maximum Range (NM)
900
Persons On Board
Maximum Climb Rate (ft/min)
3000

Performance

Climb
LevelSpeedRate
000-100180-2151000-2000
100-200170-180500-800
200-300170-180500-800
Descent
LevelSpeedRate
000-1001801000
100-2001801000
200-3001801000
