| ICAO Code | Classification | Category |
|---|---|---|
M4 |
L1P |
L/G |
Technical Data
Wing Span (m)
9
Length (m)
6.7
Height (m)
1.9
MTOW (t)
0.9
Fuel Capacity (ltr)
160
Maximum Range (Nm)
610
Persons On Board
4
Take Off Distance (m)
200
Landing Distance (m)
200
Absolute Ceiling (x100ft)
120
Optimum Ceiling (x100ft)
80
Maximum Speed (kts/M)
156
Optimum Speed (kts/M)
125
Maximum Climb Rate (ft/min)
700
Manufacturers
MAULE M-4
MAULE M-4 Astro Rocket
MAULE M-4 Bee Dee
MAULE M-4 Jetasen
MAULE M-4 Rocket
MAULE M-4 Sport 100
MAULE M-4 Strata Rocket
SAASA M-1 Cuauhtemoc
