| ICAO Code | Classification | Category |
|---|---|---|
BT36 |
L1P |
L/G |
Technical Data
Wing Span (m)
11.5
Length (m)
8.4
Height (m)
2.6
MTOW (t)
1.7
Fuel Capacity (ltr)
400
Maximum Range (Nm)
1000
Persons On Board
6
Take Off Distance (m)
720
Landing Distance (m)
520
Absolute Ceiling (x100ft)
250
Optimum Ceiling (x100ft)
100
Maximum Speed (kts/M)
200
Optimum Speed (kts/M)
190
Maximum Climb Rate (ft/min)
1050
Manufacturers
BEECH A36TC Bonanza
BEECH B36TC Bonanza
RAYTHEON B36TC Bonanza
