ICAO CodeClassificationCategory

BE30

L2T

L

BE30thumb image
BE30thumb image
BE30thumb image

Manufacturers

BEECH
Super King Air (300)
RAYTHEON
300 Super King Air

Technical Data

Wing Span
13.3
Length (m)
16.6
Height (m)
4.3
Take Off Distance (m)
520
Landing Distance (m)
780
Absolute Ceiling (x100ft)
350
Optimum Ceiling (x100ft)
310
Maximum Speed (kts/M)
315
Optimum Speed (kts/M)
299
Fuel Capacity (ltr)
2100
MTOW (t)
6.3
Maximum Range (NM)
1590
Persons On Board
15
Maximum Climb Rate (ft/min)
3000

Performance

Climb
LevelSpeedRate
000-100175-1801000-1670
100-200175-1801000-1670
200-300175-180500-800
300-400175-180500-800
Descent
LevelSpeedRate
000-1001801000
100-2001801000
200-3001801000
300-4001801000
