ICAO CodeClassificationCategory

BD10

L1J

L

BD10thumb image
BD10thumb image
BD10thumb image

Manufacturers

BEDE
BD-10
PEREGRINE
PJ-2 Falcon
PEREGRINE
PJ-3 Falcon

Technical Data

Wing Span
6.5
Length (m)
8.5
Height (m)
2.4
Take Off Distance (m)
200
Landing Distance (m)
500
Absolute Ceiling (x100ft)
450
Optimum Ceiling (x100ft)
410
Maximum Speed (kts/M)
800
Optimum Speed (kts/M)
530
Fuel Capacity (ltr)
1000
MTOW (t)
Maximum Range (NM)
1800
Persons On Board
Maximum Climb Rate (ft/min)
3000

Performance

Climb
LevelSpeedRate
000-100275-2902000-4000
100-200335-3402000-3000
200-300350-3601000-2000
300-400395-400600-1200
400-500395-400600-1200
Descent
LevelSpeedRate
000-1001802000
100-2002402000
200-3003602000
300-4003602000
400-5003602000
