ICAO CodeClassificationCategory

B744

L4J

H

B744thumb image
B744thumb image
B744thumb image

Manufacturers

BOEING
747-400 (international winglets)
BOEING
YAL-1

Technical Data

Wing Span
64.4
Length (m)
70.7
Height (m)
19.4
Take Off Distance (m)
3352
Landing Distance (m)
2072
Absolute Ceiling (x100ft)
450
Optimum Ceiling (x100ft)
350
Maximum Speed (kts/M)
507
Optimum Speed (kts/M)
492
Fuel Capacity (ltr)
216800
MTOW (t)
396.9
Maximum Range (NM)
7260
Persons On Board
450
Maximum Climb Rate (ft/min)
1500

Performance

Climb
LevelSpeedRate
000-100240-2701250-2000
100-200385-4201430-2000
200-300345-3601000-1430
300-400240-250670-1000
400-500240-270500-670
Descent
LevelSpeedRate
000-1002501670
100-2004202000
200-3004802000
300-4004802000
400-5004501000
