ICAO CodeClassificationCategory

B463

L4J

M

B463thumb image
B463thumb image
B463thumb image

Manufacturers

BRITISH AEROSPACE
BAe-146-300

Technical Data

Wing Span
26.2
Length (m)
31
Height (m)
8.6
Take Off Distance (m)
1811
Landing Distance (m)
1268
Absolute Ceiling (x100ft)
310
Optimum Ceiling (x100ft)
300
Maximum Speed (kts/M)
429
Optimum Speed (kts/M)
377
Fuel Capacity (ltr)
12900
MTOW (t)
44.2
Maximum Range (NM)
1520
Persons On Board
100-123
Maximum Climb Rate (ft/min)
2000

Performance

Climb
LevelSpeedRate
000-100240-2501000-1500
100-200270-3001000-1430
200-300300-330770-1000
300-400350-360670-1000
400-500350-360670-1000
Descent
LevelSpeedRate
000-1002601430
100-2003601500
200-3004201670
300-4003601250
400-5003601250
