| ICAO Code | Classification | Category |
|---|---|---|
AVLN |
A1T |
L/G |
Technical Data
Wing Span (m)
13.4
Length (m)
9.7
Height (m)
3.8
MTOW (t)
1.5
Fuel Capacity (ltr)
575
Maximum Range (Nm)
900
Persons On Board
6
Take Off Distance (m)
244
Landing Distance (m)
200
Absolute Ceiling (x100ft)
270
Optimum Ceiling (x100ft)
200
Maximum Speed (kts/M)
200
Optimum Speed (kts/M)
174
Maximum Climb Rate (ft/min)
2200
Manufacturers
AIRMASTER Avalon 680
