ICAO CodeClassificationCategory

AJET

L2J

M

AJETthumb image
AJETthumb image
AJETthumb image

Manufacturers

AOI
Alpha Jet
DASSAULT-DORNIER
Alpha Jet
SABCA
Alpha Jet

Technical Data

Wing Span
8.1
Length (m)
12.2
Height (m)
4.1
Take Off Distance (m)
850
Landing Distance (m)
1250
Absolute Ceiling (x100ft)
490
Optimum Ceiling (x100ft)
250
Maximum Speed (kts/M)
540 / .86
Optimum Speed (kts/M)
420
Fuel Capacity (ltr)
2500
MTOW (t)
7.2
Maximum Range (NM)
1500
Persons On Board
Maximum Climb Rate (ft/min)
11200

Performance

Climb
LevelSpeedRate
000-100270-3002000-3000
100-200440-4502500-3330
200-300420-4302000-2500
300-400545-6001250-1820
400-500525-6001000-1250
500-600525-6001000-1250
Descent
LevelSpeedRate
000-1003002000
100-2003752500
200-3004503000
300-4004202000
400-5005401000
500-6005401000
