ICAO CodeClassificationCategory

A500

L2P

L

A500thumb image
A500thumb image
A500thumb image

Manufacturers

ADAM (2)
A-500 CarbonAero

Technical Data

Wing Span
13.4
Length (m)
11.1
Height (m)
2.9
Take Off Distance (m)

Landing Distance (m)

Absolute Ceiling (x100ft)
250
Optimum Ceiling (x100ft)
220
Maximum Speed (kts/M)
250
Optimum Speed (kts/M)
220
Fuel Capacity (ltr)
500
MTOW (t)
2.8
Maximum Range (NM)
1100
Persons On Board
Maximum Climb Rate (ft/min)
1800

Performance

Climb
LevelSpeedRate
000-100180-2151000-2000
100-200170-180500-800
200-300170-180500-800
Descent
LevelSpeedRate
000-1001801000
100-2001801000
200-3001801000
