ICAO CodeClassificationCategory

A50

L4J

H

A50thumb image
A50thumb image
A50thumb image

Manufacturers

BERIEV
A-50
BERIEV
Be-976
ILYUSHIN
A-50
ILYUSHIN
Be-976

Technical Data

Wing Span
50.5
Length (m)
46.5
Height (m)
14.7
Take Off Distance (m)
2300
Landing Distance (m)
1500
Absolute Ceiling (x100ft)
450
Optimum Ceiling (x100ft)
330
Maximum Speed (kts/M)
458
Optimum Speed (kts/M)
430
Fuel Capacity (ltr)
109500
MTOW (t)
190
Maximum Range (NM)
3940
Persons On Board
15
Maximum Climb Rate (ft/min)
1970

Performance

Climb
LevelSpeedRate
000-100215-2351000-1500
100-200430-4801430-2000
200-300360-3751000-1250
300-400330-360670-910
400-500330-360670-910
Descent
LevelSpeedRate
000-1002601430
100-2004501670
200-3004301430
300-4003751250
400-5003751250
