ICAO CodeClassificationCategory

A148

L2J

M

A148thumb image
A148thumb image
A148thumb image

Manufacturers

ANTONOV
An-148

Technical Data

Wing Span
28.9
Length (m)
29.1
Height (m)
8.2
Take Off Distance (m)
1800
Landing Distance (m)
2100
Absolute Ceiling (x100ft)
470
Optimum Ceiling (x100ft)
410
Maximum Speed (kts/M)
470
Optimum Speed (kts/M)
440
Fuel Capacity (ltr)
12100
MTOW (t)
39.5
Maximum Range (NM)
2700
Persons On Board
80
Maximum Climb Rate (ft/min)


Performance

Climb
LevelSpeedRate
000-100300-3101670-2500
100-200340-4301670-3000
200-300420-4302000-2500
300-400545-6001250-1820
400-500525-6001000-1250
500-600525-6001000-1250
Descent
LevelSpeedRate
000-1003602000
100-2004503000
200-3004503000
300-4004202000
400-5005401000
500-6005401000
