ICAO CodeClassificationCategory

A1

L1P

M

A1thumb image
A1thumb image
A1thumb image

Manufacturers

DOUGLAS
AD Skyraider
DOUGLAS
EA-1 Skyraider

Technical Data

Wing Span
15.4
Length (m)
11.8
Height (m)
4.7
Take Off Distance (m)
600
Landing Distance (m)
600
Absolute Ceiling (x100ft)
310
Optimum Ceiling (x100ft)
215
Maximum Speed (kts/M)
280
Optimum Speed (kts/M)
163
Fuel Capacity (ltr)
3150
MTOW (t)
11.3
Maximum Range (NM)
2500
Persons On Board
Maximum Climb Rate (ft/min)
3700

Performance

Climb
LevelSpeedRate
000-100200-2051000-1500
100-200180-190830-1000
200-300230-240330-500
300-400240-250330-500
Descent
LevelSpeedRate
000-1002701500
100-2002401430
200-3002401000
300-4002401000
