ICAO CodeClassificationCategory

A002

G1P

L

A002thumb image
A002thumb image
A002thumb image

Manufacturers

IRKUT
A-002

Technical Data

Wing Span
Length (m)
5.9
Height (m)
3.3
Take Off Distance (m)
90
Landing Distance (m)
10
Absolute Ceiling (x100ft)
100
Optimum Ceiling (x100ft)
80
Maximum Speed (kts/M)
113
Optimum Speed (kts/M)
97
Fuel Capacity (ltr)
150
MTOW (t)
0.9
Maximum Range (NM)
270
Persons On Board
Maximum Climb Rate (ft/min)
1000

Performance

Climb
LevelSpeedRate
000-04085-90560-840
040-08085-95510-770
080-30090-95225-340
Descent
LevelSpeedRate
000-04075320
040-08085430
080-30090450
